YBK3-200L2-2防爆电机
YBK3系列煤矿井下用隔爆型三相异步电动机是为煤矿井下采掘工作面机械设计的专用电动机，机座由钢板焊接成形，风罩、接线盒、绝缘结构采取加强措施，电气性能、安装尺寸、额定功率等均与YB2电动机相同。
本系列电动机的防爆性能符合GB3836.1-2000《爆炸性气体环境用电气设备第1部分：通用要求》和GB3836.2－2000《爆炸性气体环境用电气设备第2部分：隔爆型“d”》标准的规定，制成隔爆型Exd Ⅰ．适用于煤矿井下采掘工作面。
二、主要技术参数：
1.额定电压：380V、660V、380／660V、660／1140V
2.额定频率：50Hz
3.防护等级：IP55
4.冷却方式：IC411
5.工作制：S1
6.绝缘等级：F
7.安装形式：IMB3、IMB5、IMB35等YBK3-100L-2-3
YBK3-100L1-4-2.2
YBK3-100L2-4-3
YBK3-100L-6-1.5
YBK3-100L1-8-0.75
YBK3-100L2-8-1.1
YBK3-112M-2-4
YBK3-112M-4-4
YBK3-112M-6-2.2
YBK3-112-8-1.5
YBK3-132S1-2-5.5
YBK3-132S2-2-7.5
YBK3-132S-4-5.5
YBK3-132M-4-7.5
YBK3-132S-6-3
YBK3-132M1-6-4
YBK3-132M2-6-5.5
YBK3-132S-8-2.2
YBK3-132M-8-3
YBK3-160M1-2-11
YBK3-160M2-2-15
YBK3-160L-2-18.5
YBK3-160M-4-11
YBK3-160L-4-15
YBK3-160M-6-7.5
YBK3-160L-6-11
YBK3-160M1-8-4
YBK3-160M2-8-5.5
YBK3-160L-8-7.5
YBK3-180M-2-22
YBK3-180M-4-18.5
YBK3-180L-4-22
YBK3-180L-6-15
YBK3-180L-8-11
YBK3-200L1-2-30
YBK3-200L2-2-37
YBK3-200L-4-30
YBK3-200L1-6-18.5
YBK3-200L2-6-22
YBK3-200L-8-15
YBK3-225M-2-45
YBK3-225M-4-45
YBK3-225M-6-30
YBK3-225S-8-18.5
YBK3-225M-8-22
YBK3-250M-2-55
YBK3-250M-4-55
YBK3-250M-6-37
YBK3-250M-8-30
YBK3-280S-2-75
YBK3-280M-2-90
YBK3-280S-4-75
YBK3-280M-4-90
YBK3-280S-6-45
YBK3-280M-6-55
YBK3-280S-8-37
YBK3-280M-8-45
YBK3-315S-2-110
YBK3-315M-2-132
YBK3-315L1-2-160
YBK3-315L2-2-200
YBK3-315S-4-110
YBK3-315M-4-132
YBK3-315L1-4-160
YBK3-315L2-4-200
YBK3-315S-6-75
YBK3-315M-6-90
YBK3-315L1-6-110
YBK3-315L2-6-132
YBK3-315S-10-45
YBK3-315M-10-55
YBK3-315L1-10-75
YBK3-315L2-10-90
YBK3-315S-8-55
YBK3-315M-8-75
YBK3-315L1-8-90
YBK3-315L2-8-110
YBK3-355S1-2-185
YBK3-355S2-2-200
YBK3-355M1-2-220
YBK3-355M2-2-250
YBK3-355L1-2-280
YBK3-355L2-2-315
YBK3-355S1-4-185
YBK3-355S2-4-200
YBK3-355M1-4-220
YBK3-355M2-4-250
YBK3-355L1-4-280
YBK3-355L2-4-315
YBK3-355S-6-160
YBK3-355M1-6-185
YBK3-355M2-6-200
YBK3-355L1-6-220
YBK3-355L2-6-250
YBK3-355S-8-132
YBK3-355M-8-160
YBK3-355L1-8-185
YBK3-355L2-8-200
YBK3-355S-10-90
YBK3-355M1-10-110
YBK3-355M2-10-132
YBK3-355L1-10-160
YBK3-355L2-10-185
|
