日本岛津SHIMADZU SGP1，SGP2  PUMPS / 昆山苏美自动化科技有限公司专业供应.
SGP1,SGP2 seriesSGP1 and SGP2 series high pressure gear pumps are an advanced version of conventional gear pumps using specialized cast iron body. They can withstand any adverse conditions of surge pressure, wide temperature and wide speed range with long life. Especially they maintains high performance during high temperature and low speed operation. Ceramic coating in SGP2 pump realizes invented step in sealing device for leakage loss



型 号 理论排量 mL/r 额定压力MPa 最高压力 MPa 最高转速 r/min 最低转速 r/min
SGP1-16 15.9 20.5 24.53 4000 400
SGP1-18 17.9
SGP1-20 20.0
SGP1-23 23.3
SGP1-25 24.5 3500
SGP1-27 27.3 3500
SGP1-28.2 28.2 3000
SGP1-30 29.2
SGP1-30.8 30.4
SGP1-31.9 31.5
SGP1-32 32.4
SGP1-34 33.2
SGP1-36

35.7


型号 最高压力 额定压力 排量 配管尺寸 容许转数rpm 重量（kg）
(MPa) （MPa） mℓ/rev 入口 出口
L型 F型 L型 F型 最低 最高
SGP1A16 24.5 20.6 16.2 Ø25 PT1" Ø19 PT3/4" 500 4000 3.3
SGP1A18 24.5 20.6 18.3 Ø25 PT1" Ø19 PT3/4" 500 4000 3.4
SGP1A20 24.5 20.6 20,4 Ø25 PT1" Ø19 PT3/4" 500 4000 3.5
SGP1A23 24.5 20.6 23.7 Ø25 PT1" Ø19 PT3/4" 400 4000 3.7
SGP1A25 24.5 20.6 24.9 Ø25 PT1" Ø19 PT3/4" 400 3500 4
SGP1A27 24.5 20.6 27.8 Ø25 PT1" Ø19 PT3/4" 400 3500 4
SGP1A30 24.5 20.6 29.9 Ø25 PT1" Ø19 PT3/4" 400 3000 4.1
SGP1A32 24.5 20.6 33.2 Ø25 PT1" Ø19 PT3/4" 400 3000 4.2
SGP1A34 20.6 18.6 34.1 Ø25 PT1" Ø19 PT3/4" 400 3000 4.3
SGP1A36 20.6 17.2 36.6 Ø25 PT1" Ø19 PT3/4" 400 3000

4.5

日本SHIMADZU岛津SGP1部分型号:
SGP1A16F1H1AR，SGP1A16F1H2-L，SGP1A16F1H2-R，SGP1A16F1H5-L，
SGP1A16F1H5-R，SGP1A16F2H1AL，SGP1A16F2H1AR，SGP1A16F2H2-L，
SGP1A16F2H2-R，SGP1A16F2H5-L，SGP1A16F2H5-R，SGP1A16D1H1AL，
SGP1A16D1H1AR，SGP1A16D1H2-L，SGP1A16D1H2-R，SGP1A16D1H5-L，
SGP1A16D1H5-R，SGP1A16D2H1AL，SGP1A16D2H1AR，SGP1A16D2H2-L，
SGP1A16D2H2-R，SGP1A16D2H5-L，SGP1A16D2H5-R，SGP1-18F1H1-L，
SGP1-18F1H1-R，SGP1-18F1H2-L，SGP1-18F1H2-R，SGP1-18F1H5-L，
SGP1-18F1H5-R，SGP1-18F2H1-L，SGP1-18F2H1-R，SGP1-18F2H2-L，
SGP1-18F2H2-R，SGP1-18F2H5-L，SGP1-18F2H5-R，SGP1-18D1H1-L，
SGP1-18D1H1-R，SGP1-18D1H2-L，SGP1-18D1H2-R，SGP1-18D1H5-L，
SGP1-18D1H5-R，SGP1-18D2H1-L，SGP1-18D2H1-R，SGP1-18D2H2-L，
SGP1-18D2H2-R，SGP1-18D2H5-L，SGP1-18D2H5-R，SGP1A18F1H1AL，
SGP1A18F1H1AR，SGP1A18F1H2-L，SGP1A18F1H2-R，SGP1A18F1H5-L，
SGP1A18F1H5-R，SGP1A18F2H1AL，SGP1A18F2H1AR，SGP1A18F2H2-L，SGP1A18F2H2-R，SGP1A18F2H5-L，SGP1A18F2H5-R，SGP1A18D1H1AL，SGP1A18D1H1AR，SGP1A18D1H2-L，SGP1A18D1H2-R，SGP1A18D1H5-L，SGP1A18D1H5-R，SGP1A18D2H1AL，SGP1A18D2H1AR，SGP1A18D2H2-L，SGP1A18D2H2-R，SGP1A18D2H5-L，SGP1A18D2H5-R，SGP1-20F1H1-L，SGP1-20F1H1-R，GP1-20F1H2-L，SGP1-20F1H2-R，SGP1-20F1H5-L，SGP1-20F1H5-R，SGP1-20F2H1-L，SGP1-20F2H1-R，SGP1-20F2H2-L，SGP1-20F2H2-R，SGP1-20F2H5-L，SGP1-20F2H5-R，SGP1-20D1H1-L，SGP1-20D1H1-R，SGP1-20D1H2-L，SGP1-20D1H2-R，SGP1-20D1H5-L，SGP1-20D1H5-R，SGP1-20D2H1-L，SGP1-20D2H1-R，SGP1-20D2H2-L，SGP1-20D2H2-R，SGP1-20D2H5-L，SGP1-20D2H5-R，SGP1A20F1H1AL，SGP1A20F1H1AR，SGP1A20F1H2-L，SGP1A20F1H2-R，SGP1A20F1H5-L，SGP1A20F1H5-R，SGP1A20F2H1AL，SGP1A20F2H1AR，SGP1A20F2H2-L，SGP1A20F2H2-R，SGP1A20F2H5-L，SGP1A20F2H5-R，SGP1A20D1H1AL，
SGP1A20D1H1AR，SGP1A20D1H2-L，SGP1A20D1H2-R，SGP1A20D1H5-L，SGP1A20D1H5-R，SGP1A20D2H1AL，SGP1A20D2H1AR，SGP1A20D2H2-L，SGP1A20D2H2-R，SGP1A20D2H5-L，SGP1A20D2H5-R，SGP1-23F1H1-L，SGP1-23F1H1-R，SGP1-23F1H2-L，SGP1-23F1H2-R，
SGP1-23F1H5-L，SGP1-23F1H5-R，SGP1-23F2H1-L，SGP1-23F2H1-R，
SGP1-23F2H2-L，SGP1-23F2H2-R，SGP1-23F2H5-L，SGP1-23F2H5-R，
SGP1-23D1H1-L，SGP1-23D1H1-R，GP1-23D1H2-L，SGP1-23D1H2-R，
SGP1-23D1H5-L，SGP1-23D1H5-R，SGP1-23D2H1-L，SGP1-23D2H1-R，
SGP1-23D2H2-L，SGP1-23D2H2-R，
